How to Debug a Node.js App on AWS ECS Fargate Using Port Forwarding (Step-by-Step Guide)

Oct 29, 20254 min read

At some point in their lives, every software engineer eventually faces the task of debugging an app live on a remote server. If that app happens to be running on AWS ECS Fargate, getting into that container safely is possible, but not immediately obvious.

Full disclosure: I haven’t done this exact thing before, but I have used the same port-forwarding trick to peek into our RDS instances via an ECS task acting as a jumpbox. So yes, I tested these instructions, and yes, they actually work.

The Setup

Here’s what we have:

A Node.js app deployed to AWS ECS Fargate
Inside a private VPC subnet
Without SSH access (Fargate doesn’t do that)
VS Code (or some other IDE with Node.js inspector support)

Step 1: Enable Node.js Inspector in Your Fargate Task

To attach a debugger, your Node.js process must start with the inspector enabled. This can be achieved by passing a flag to the node command.

node --inspect=127.0.0.1:9229 server.js

Or by adding the inspect flag to the NODE_OPTIONS environmental variable.

NODE_OPTIONS="--inspect=127.0.0.1:9229"

Since we’re using ECS, adding flag to the node command would require modifying Dockerfile or overriding command in the task definition, so I’d suggest the environmental variable approach.

{
  "containerDefinitions": [
    {
      "name": "...",
      "image": "...",
      "essential": true,
      "environment": [
        {
          "name": "NODE_OPTIONS",
          "value": "--inspect=127.0.0.1:9229"
        }
      ]
    }
  ]
}

Step 2: Grant SSM and ECS Exec Permissions

To enable secure shell-like access to your ECS Fargate container, configure ECS Exec and grant SSM permissions. Attach this AWS IAM policy to your ECS task execution role:

arn:aws:iam::aws:policy/AmazonSSMManagedInstanceCore

Enable ECS Exec on your service:

aws ecs update-service \
  --cluster my-cluster \
  --service my-service \
  --enable-execute-command

If you’re changing it through the console, it’s hidden under Troubleshooting → Enable Execute Command.

Step 3: Identify the Running Task ID

Before establishing a session, identify the running ECS task ARN and container runtime ID.

List your tasks:

aws ecs list-tasks --cluster my-cluster

You’ll get something like:

{
  "taskArns": [
    "arn:aws:ecs:us-east-1:123456789012:task/my-cluster/abc123def456ghi789"
  ]
}

The last part of the ARN (abc123def456ghi789) is your Task ID.

Step 4: Create an SSM Port Forwarding Session

Use AWS Systems Manager Session Manager to create a secure port forwarding tunnel from your local machine to the Node.js process inside the Fargate task.

Here’s where the real black magic starts. AWS won’t just give you a SSM target ID for the Fargate task, you have to construct it yourself using this template:

ecs:<cluster_name>_<task_id>_<container_runtime_id>

Get the container runtime ID:

aws ecs describe-tasks \
 --cluster my-cluster \
 --task <task_arn> \
 --query "tasks[].containers"

You’ll get a massive JSON blob, and somewhere in that mess hides the runtimeId field you actually care about. There might be a few of them actually, one for each container in the task. And yes, the runtimeId contains task id in it.

Then start the port forwarding:

aws ssm start-session \
 --target "ecs:my-cluster_cb39a47ef2ef45f4b947236bf00aeadd_cb39a47ef2ef45f4b947236bf00aeadd-3935363592" \
 --document-name AWS-StartPortForwardingSessionToRemoteHost \
 --parameters '{"host":["127.0.0.1"],"portNumber":["9229"],"localPortNumber":["9229"]}'

This opens a local port (9229) and forwards traffic securely to the Node.js process in your container.

Pro tip: We’re forwarding to 127.0.0.1 here, but you can forward to any IP or hostname accessible from the ECS task.

Step 5: Attach VS Code Debugger

Once the tunnel is active, open VS Code and attach your debugger to localhost:9229. You’re now live-debugging inside Fargate.

In .vscode/launch.json:

{
  "type": "node",
  "request": "attach",
  "name": "Attach to Fargate",
  "address": "localhost",
  "port": 9229,
  "localRoot": "${workspaceFolder}",
  "remoteRoot": "/usr/src/app"
}

And that’s all.

If you don’t know the remoteRoot , then you can get into the container and look around to check it.

aws ecs execute-command --cluster my-cluster \
 --task <task_arn> \
 --interactive \
 --command "/bin/sh" \
 --container <container name>

Alternative: Chrome debugger (chrome://inspect). Usually works, but tends to have issues with source maps.

TL;DR Cheat Sheet

# 1. Make sure your Node.js app runs with --inspect flag
NODE_OPTIONS="--inspect=127.0.0.1:9229"

# 2. Give ECS task SSM permissions
# 3. Enable ECS Exec
aws ecs update-service —service my-service —cluster my-cluster —enable-execute-command

# 4. Get you task arn
aws ecs list-tasks --cluster my-cluster

# 5. Get your container runtime id
aws ecs describe-tasks \
 --cluster <cluster> \
 --region us-east-2 \
 --task <task_arn> \
 --query "tasks[].containers"

# 6. Start port forwarding
aws ssm start-session \
 --target ecs:<cluster>_<task>_<runtime_id> \
 --document-name AWS-StartPortForwardingSessionToRemoteHost \
 --parameters '{"host":["127.0.0.1"],"portNumber":["9229"],"localPortNumber":["9229"]}'
